TOPWIN 0.99'' tft display panel 40x160 IPS
New Arrival 0.99 Inch Small Vertical Display 40*160 Resolution SPI Interface GC9D01
1 LCD Size 0.99 inch(Diagonal) -
2 Display Mode Normally black -
3 Resolution 40(H)RGB x 160(V) -
4 Dot pitch 0.1524(H) x 0.1524(V) mm -
5 Active area 6.096(H) x 24.384(V) mm -
6 Module size 8.6(H) x 29.8(V) x1.5(D) mm -
7 Color arrangement RGB Vtertical stripe -
8 Interface SPI4 LINE
9 Drive IC GC9D01
10 Viewing Direction All View
11 Operating Temp. -20℃~ + 70℃
12 Storage Temp. -30℃~+ 80℃
- 产品描述
- Features
-
1 LCD Size 0.99 inch(Diagonal) -
2 Display Mode Normally black -
3 Resolution 40(H)RGB x 160(V) -
4 Dot pitch 0.1524(H) x 0.1524(V) mm -
5 Active area 6.096(H) x 24.384(V) mm -
6 Module size 8.6(H) x 29.8(V) x1.5(D) mm -
7 Color arrangement RGB Vtertical stripe -
8 Interface SPI4 LINE
9 Drive IC GC9D01
10 Viewing Direction All View
11 Operating Temp. -20℃~ + 70℃
12 Storage Temp. -30℃~+ 80℃
