TOPWIN 2inch TFT 240x320 IC ST7789V
1 LCD Size 2.0 inch(Diagonal) -
2 Display Mode Normally black -
3 Resolution 240(H)RGB x 320(V) -
4 Dot pitch 0.051(H) x 0.153(V) mm -
5 Active area 30.6(H) x 40.8(V) mm -
6 Module size 34.6(H) x 47.8(V) x2.05(D) mm -
7 Color arrangement RGB Vtertical stripe -
9 Drive IC ST7789V -
10 Luminance(cd/m2) 300 (TYP)
11 Viewing Direction ALL View
12 Backlight 4White LED
13 Operating Temp. -20℃~ + 70℃
14 Storage Temp. -30℃~+ 80℃
- 产品描述
- Features
-
1 LCD Size 2.0 inch(Diagonal) -
2 Display Mode Normally black -
3 Resolution 240(H)RGB x 320(V) -
4 Dot pitch 0.051(H) x 0.153(V) mm -
5 Active area 30.6(H) x 40.8(V) mm -
6 Module size 34.6(H) x 47.8(V) x2.05(D) mm -
7 Color arrangement RGB Vtertical stripe -
9 Drive IC ST7789V -
10 Luminance(cd/m2) 300 (TYP)
11 Viewing Direction ALL View
12 Backlight 4White LED
13 Operating Temp. -20℃~ + 70℃
14 Storage Temp. -30℃~+ 80℃
