TOPWIN 2.7inch oled display module SSD1322 Parallel SPI

Outline Drawing :85.0(W)x58.0(H)x7.0Max(T) mm

View Area: 65.0(W)x33.0(H) mm

Active Area :61.41(W)x30.69(H) mm

Lattice :128dots x 64dots --

Pixel Pitch :0.48(W)x0.48(H) mm

Pixel Size : 0.45(W)x0.45(H) mm

Display Mode:Passive Matrix—OLED

Color:Yellow/White

Interface :8-Bit 68XX/80XX Parallel、 SPI

Drive Duty :1/64

Driver IC :SSD1322

INQUIRY

产品描述
Features

Outline Drawing :85.0(W)x58.0(H)x7.0Max(T) mm

View Area: 65.0(W)x33.0(H) mm

Active Area :61.41(W)x30.69(H) mm

Lattice :128dots x 64dots --

Pixel Pitch :0.48(W)x0.48(H) mm

Pixel Size : 0.45(W)x0.45(H) mm

Display Mode:Passive Matrix—OLED

Color:Yellow/White

Interface :8-Bit 68XX/80XX Parallel、 SPI

Drive Duty :1/64

Driver IC :SSD1322
