TOPWIN 1.08'' tft display 128x220 IC GC9203
1 LCD Size 1.08 inch(Diagonal) -
2 Display Mode Normally black -
3 Resolution 128(H)RGB x 220(V) -
4 Dot pitch 0.108(H) x 0.108(V) mm -
5 Active area 13.824(H) x 23.76(V) mm -
6 Module size 16.12(H) x 29.76(V) x1.52(D) mm -
7 Color arrangement RGB Vtertical stripe -
8 Interface 4 Line SPI -
9 Drive IC GC9203 -
10 Luminance(cd/m2) 400 (TYP)
11 Viewing Direction All View
12 Backlight 1 White LED
13 Operating Temp. -20℃~ + 70℃ ℃
14 Storage Temp. -30℃~+ 80℃ ℃
- 产品描述
- Features
-
1 LCD Size 1.08 inch(Diagonal) -
2 Display Mode Normally black -
3 Resolution 128(H)RGB x 220(V) -
4 Dot pitch 0.108(H) x 0.108(V) mm -
5 Active area 13.824(H) x 23.76(V) mm -
6 Module size 16.12(H) x 29.76(V) x1.52(D) mm -
7 Color arrangement RGB Vtertical stripe -
8 Interface 4 Line SPI -
9 Drive IC GC9203 -
10 Luminance(cd/m2) 400 (TYP)
11 Viewing Direction All View
12 Backlight 1 White LED
13 Operating Temp. -20℃~ + 70℃ ℃
14 Storage Temp. -30℃~+ 80℃ ℃
